4. Remove any currently installed module(s), if it/they need to be upgraded or
replaced
5. Gently pull the two release latches (
of the memory socket in the direction indicated by the arrows.
2
6. The module will pop-up, and you can remove it.
3
7. Repeat the process for the second module if necessary.
8. Insert a new module holding it at about a 30° angle and fit the connectors
firmly into the memory slot.
Figure 6 -
& in
1 2
1
3
Upgrading the System Memory (RAM) 6 - 7
Upgrading The Computer
5)
on the sides
Contact Warning
Be careful not to touch
the metal pins on the
module's
edge. Even the clean-
est hands have oils
which can attract parti-
cles, and degrade the
module's
mance.
Figure 6 - 5
Memory Sockets
connecting
perfor-
One & Two
6
