Left Side View
1
1
Optical Device Bay
The optical device bay will contain a 5.25" (12.7mm height) CD/DVD type
device. The actual device will depend on your purchase option (see
on page A - 2
for options). For more information on using the drive please
refer to
"Optical Device" on page 2 -
If you need to manually eject a CD/DVD (e.g. due to an unexpected power interrup-
tion) you may push the end of a straightened paper clip into the emergency eject
hole. Do not use a sharpened pencil or similar object that may break and become
lodged in the hole.
Model A
2
Model B
2
11.
CD Emergency Eject
4
5
2
3
2
4
5
2
3
2
"Storage"
Introduction
Figure 1 - 4
Left Side View
1.
Optical Device Bay
2.
3 * USB 2.0/1.1
Ports
3.
3-in-1 Card Reader
for SD/MS & MS
Pro/MMC
4.
PC Card Slot
5.
PC Card Slot Eject
Button
Left Side View 1 - 13
