Introduction
1
Card Reader Cover
Make sure you keep
the cover in the card
reader when not is
use. This will help pre-
vent foreign objects
and/or dust getting in
to the card reader.
1 - 14 Left Side View

USB 2.0/1.1 Port

These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for
low-speed peripherals such as keyboards, mice or scanners, and for high-
speed peripherals such as external HDDs, digital video cameras or high-speed
scanners etc. Devices can be plugged into the computer, and unplugged from
the computer, without the need to turn the system off (if the power rating of
your USB device is 500mA or above, make sure you use the power supply
which comes with the device).

3-in-1 Card Reader

The card reader allows you to use some of the latest digital storage card for-
mats (Secure Digital / Memory Stick & Memory Stick Pro /Multi Media
Card). Push the card into the slot and it will appear as a removable device (see
"3-in-1 Flash Card Reader Module" on page 7 -

PC Card Slot

The 3.3V/5V slot may be used for a Type-II PC card (PC Cards were also pre-
viously referred to as PCMCIA) and fully supports Cardbus. Refer to
Card Slot" on page 2 - 15
2).
for more information.
"PC
