Installing a 3.5-inch Drive into a Drive Bay

The 3.5-inch bay is located underneath the 5.25-inch drive. To install a drive into the 3.5-inch bay:
NOTE:
Install guide screws to ensure the drive will line up correctly in the drive cage and lock in
place. HP has provided extra guide screws for the drive bays (four 6-32 standard screws and four M3
metric screws), installed in the front of the chassis, under the front bezel. A secondary hard drive uses
6-32 standard screws. All other drives (except the primary hard drive) use M3 metric screws. The HP-
supplied M3 metric screws are black and the HP-supplied 6-32 standard screws are silver. Refer to
Installing and Removing Drives on page 68
1. Follow the procedure in
5.25-inch drive and access the 3.5-inch drive bay.
CAUTION:
the electrical outlet before proceeding.
2. If you are installing a drive in a bay covered by a bezel blank, remove the front bezel then
remove the bezel blank. See
3.
Install guide screws in the holes on each side of the drive.
Figure 3-29
4.
Position the guide screws on the drive into the J-slots in the drive bay. Then slide the drive toward
the front of the computer until it locks into place.
Figure 3-30
Removing a 5.25-inch Drive from a Drive Bay on page 70
Ensure that the computer is turned off and that the power cord is disconnected from
Removing Bezel Blanks on page 55
Installing Guide Screws (Media Card Reader Shown)
Installing a Drive into the 3.5-inch Drive Bay (Media Card Reader Shown)
for illustrations of the guide screw locations.
to remove the
for more information.
Installing and Removing Drives
77
