10.
Rotate the drive cage to its upright position.
Figure 3-24
11. Connect the SATA data cable to the white SATA system board connector labeled SATA2.
12. Route the data cable through the cable guides.
CAUTION:
drive cage when raising or lowering it. One is located on the bottom side of the drive cage. The
other is located on the chassis frame under the drive cage. Ensure that the data cable is routed
through these guides before connecting it to the optical drive.
13.
Connect the power cable (1) and data cable (2) to the rear of the optical drive.
NOTE:
system board to the hard drive, then to the rear of the optical drive.
Figure 3-25
74 Chapter 3 MultiSeat ms6200 Desktop Hardware Upgrades
Rotating the Drive Cage Up
There are two cable guides that keep the data cable from being pinched by the
The power cable for the optical drive is a three-headed cable that is routed from the
Connecting the Power and Data Cables
