Rear Panel Components
Figure 1-4
Table 1-3
1
2
3
4
5
NOTE:
Arrangement and number of connectors may vary by model.
4
Chapter 1 Product Features
Rear Panel Components
Rear Panel Components
RJ-45 Network Connector
Serial Connector
PS/2 Mouse Connector (green)
Power Cord Connector
Universal Serial Bus (USB)
6
DisplayPort Monitor Connector
7
VGA Monitor Connector
8
PS/2 Keyboard Connector (purple)
9
Line-Out Connector for powered audio
devices (green)
10
Line-In Audio Connector (blue)
