SENDING FUNCTION

These settings are used to change the default settings
(initially set at the factory) for the various fax
transmission functions to settings that better meet your
needs.
RES. CON. SET
This setting is used to adjust the exposure level when
scanning an original to be faxed. The initial setting is
standard resolution and auto exposure mode.
1
Follow steps 1 through 6 of "INITIAL
PROCEDURE" (page 98).
2
Select "SENDING FUNCTION" with the [ ]
or [ ] key and then press the [OK] key.
3
Select "RES. CON. SET" with the [ ] or
[ ] key and press the [OK] key.
4
Select the resolution setting with the [ ] or
[ ] key and the exposure mode with the [ ]
or [ ] key, and then press the [OK] key.
See page 14 for information on selecting the resolution
and contrast settings.
AUTO REDUCE TX
This setting is used to have transmitted faxes reduced to
match the size of the other machine's printing paper.
"AUTO REDUCE TX" is normally enabled. If the setting
is disabled, documents are faxed in their original size.
Because the size is not adjusted to match the size of the
printing paper, part of the received fax may be cut off.
1
Follow steps 1 through 6 of "INITIAL
PROCEDURE" (page 98).
2
Select "SENDING FUNCTION" with the [ ]
or [ ] key and then press the [OK] key.
3
Select "AUTO REDUCE TX" with the [ ] or
[ ] key and then press the [OK] key.
• "AUTO REDUCE TX" is enabled and a checkmark
appears in the checkbox.
• If this procedure is performed when the setting is
enabled, the checkmark will be cleared and the
setting disabled.
ROTATE TX
This setting is used to select whether or not an A4, A5R
or 8-1/2" x 11" size original that is oriented vertically
will be rotated to a horizontal orientation
transmission. Rotation is normally enabled, and vertically
oriented originals are rotated counterclockwise. (A4, A5R
and 8-1/2" x 11" size originals that are oriented
horizontally
are not rotated.)
Rotation transmission can be selected separately for
different original sizes. To disable a rotation setting,
clear the checkbox from the appropriate setting.
1
Follow steps 1 through 6 of "INITIAL
PROCEDURE" (page 98).
2
Select "SENDING FUNCTION" with the [ ]
or [ ] key and then press the [OK] key.
3
Select "ROTATE TX" with the [ ] or [ ]
key and then press the [OK] key.
4
Select the desired original size and press
the [OK] key.
• Size selections are A4, A5R and 8-1/2" x 11".
• When a checkmark appears in the checkbox of the
selected original size, rotation transmission is enabled
for that size.
• If the procedure is performed when the setting is
enabled, the checkmark will be cleared and the
setting disabled.
5
To change the setting for another original
size, repeat step 4.
PAGE COUNTER SET
This setting lets you select whether page numbers are
printed at the top of fax pages by the receiving machine.
The normal setting is to have page numbers printed.
1
Follow steps 1 through 6 of "INITIAL
PROCEDURE" (page 98).
2
Select "SENDING FUNCTION" with the [ ]
or [ ] key and then press the [OK] key.
3
Select "PAGE COUNTER SET" with the [ ]
or [ ] key and then press the [OK] key.
• The setting is enabled (page numbers will be printed)
and a checkmark appears in the checkbox.
• If the procedure is performed when the setting is
enabled, the checkmark will be cleared and the
setting disabled.
When a fax is sent by memory transmission,
Note
the page number and total number of pages
appear at the top of each fax page. When a fax
is sent by Quick On-line transmission or direct
transmission, only the page number appears.
SYSTEM SETTINGS
before
8
105
