Tandberg Data SDLT220-320 INTEGRATION Manual page 67

Table 6-1. SCSI ID Address Selections
SCSI ID Jumper Across Pins:
9-10*
0 1
1 1
2 1
3 1
4 1
5 (default) 0
6 1
7 1
8 1
9 1
10 1
11 1
12 1
13 1
14 1
15 1
0 = No Jumper installed, 1 = Jumper installed
* Jumpering Pins 9-10 forces the drive to ignore the firmware value
and read the value jumpered on the block.
CHAPTER 6: SCSI and Controller Interface Specification
7-8 5-6 3-4
0 0 0
0 0 0
0 0 1
0 0 1
0 1 0
0 0 0
0 1 1
0 1 1
1 0 0
1 0 0
1 0 1
1 0 1
1 1 0
1 1 0
1 1 1
1 1 1
1-2
0
1
0
1
0
0
0
1
0
1
0
1
0
1
0
1
