5.2.5 Susceptibility and ESD Limits

The following tables list radiated, magnetic radiated, and conducted susceptibility
and ESD failure level limits for the tape system.
N : Proper ESD protection must be observed when handling
OTE
Tandberg Data tape drive products.

Table 5-4. Radiated, Magnetic Radiated, and Conducted Susceptibility

Type
Radiated Immunity:
High Frequency, Electric Fields
Magnetic Radiated:
Low Frequency, Magnetic Fields
EFT: Fast Transient (Bursts) for
Power and Data Cables
PLT: High Energy Transient
Voltage for Power Cables
Low-level Conducted‡
Interference for AC and DC
Cables
* The SDLT tape system shall maintain normal operation both in Read/Write and in Standby
conditions. No errors attributable to the test shall be encountered.
‡ Conducted: The transient voltage is the actual peak voltage above the normal AC voltage from the
power source. The maximum energy in a single pulse from the transient generator must be limited
to 2.5 W.

Table 5-5. Electrostatic Discharge (ESD) Failure Level Limits

Failure Type
Hardware
Hardware
Specifications
3 V/m (rms),
80% modulated, 1 kHz,
26 – 1000 MHz
3 A/m @ 230V/50 Hz
2 kV
1.2 kV (Differential)
2.5 kV (Common mode)
3 V/m (rms),
80% modulated, 1 kHz,
0.15 – 80 MHz
Equipment Specifications
Office 1 to 12 kV
Office Up to 15 kV
CHAPTER 5: Regulatory Requirements
Comments
No errors*
No screen distortion
No errors*
No screen distortion
No errors*
No errors*
No errors*
No screen distortion
Comments
No operator intervention (soft
recoverable allowed)
No component damage; operator
intervention allowed (soft/hard
errors allowed)
