2.4 Physical Dimensions

Table 2-1 provides physical dimensions for the SDLT tape system.
shows acceptable operating orientations for the SDLT tape system.

Table 2-1. SDLT 220/320 Physical Dimensions and Shipping Weight

Description
Height
Width
Depth
Weight*
Shipping
Weight*
* Weights depend on configuration. The packaging may change depending on the shipping weight.
Note: Mounting hole pattern for the bottom and sides of the system is industry standard.
Internal Version
82.55 mm (3.25 in) without front bezel;
86.36 mm (3.40 in) with front bezel.
146.05 mm (5.75 in) behind front bezel;
148.34 mm (5.84 in) with front bezel.
203.20 mm (8.00 in) measured from back of front
bezel; 212.09 mm (8.35 in) including front bezel.
2.38 kg (5 lbs. 4 oz)
3.77 kg (8 lbs. 5 oz)
CHAPTER 2: General Drive Specifications
Table 2-2
Tabletop Version
160.02 mm (6.30 in)
175.26 mm (6.9 in)
325.12 mm (12.8 in)
6.27 kg (13 lbs. 13 oz)
9.90 kg (21 lbs. 13 oz)
