CHAPTER 2: General Drive Specifications
Table 2-17. Operating Shock and Vibration Specifications
Shock
Pulse Shape
Peak Acceleration
Duration
Application
Vibration
Type
Frequency Range
Acceleration Level
Application
½ sine pulse
10 G
10 ms
X,Y,Z axes, twice in each axis (once in each direction)
Sine
Sweep
5 - 500 - 5 Hz
Upward and downward sweep
0.25 G
Between 22 and 500 Hz
0.010" DA
Between 5 and 22 Hz (crossover)
X,Y,Z axes
Sweep rate = 1.0 octave per minute
