2.2.1 SDLT 220/320 Library Tape Drive Interface
The library tape drive interface (for SDLT drives) is an RS-422 serial port set to
9600 baud, 8 bits per character, no parity, and 2 stop bits. All data sent to or from
the library tape drive interface consists of bit-wise encoded hex values.
2.2.2 SDLT 220/320 Front Panel LEDs
Figure 2-2
shows the color, position, and meaning (interpretation) of the three
front panel LEDs.
Figure 2-2. SDLT 220/320 Front Panel LEDs
CHAPTER 2: General Drive Specifications
