Opening the Blade Server Cover

The following illustration shows how to open the cover on a blade server.
To open the blade server cover, complete the following steps:
1. Read the safety information beginning on
Information"
2. If the blade server is installed in a Intel® Blade Server Chassis SBCE, remove it (see
"Removing the Blade Server from an Intel® Blade Server Chassis SBCE" on page 17
for instructions).
3. Carefully lay the blade server down on a flat, non-conductive surface, with the cover
side up.
4. Press the blade-cover release on each side of the blade server and lift the cover open,
as shown in the illustration.
5. Lay the cover flat, or lift it from the blade server and store for future use.
Caution: Hazardous energy is present when the blade server is connected to the power source.
Always replace the blade cover before installing the blade server.
18
Cover
Pins
Blade-Cover
Release
and "Installation Guidelines" on page
Intel® Server Compute Blade SBXD62 Installation and User's Guide
Blade-Cover
Release
AF000436
page 65 in Appendix C, "Safety
15.
