Intel Server Compute Blade SBXD62 Specifications
The following table is a summary of the features and specifications of the blade server.
Note: Power, cooling, removable-media drives, external ports, and advanced system
management are provided by the Intel® Blade Server Chassis SBCE.
Microprocessor:
Supports up to two
microprocessors
® ®
Dual-Core Intel Xeon
GHz or 2.0 GHz
Chipset:
®
Intel E7520 chipset
Memory:
Dual channel 400 MHz (DDR2)
with 4 dual inline memory module
(DIMM) slots (16 GB maximum)
Type: 2-way interleaved, DDR2,
PC3200, ECC SDRAM registered
®
x4 (Intel x4 Single Device Data
Correction) DIMMs only
Supports 256 MB, 512 MB, 1 GB,
2 GB, and 4 GB (4 DIMM slots)
Drives: Support for two internal
small-form-factor SAS drives
Intel® Server Compute Blade SBXD62 Installation and User's Guide
Integrated functions:
Dual Gigabit Ethernet controllers
Expansion card interface
DP 1.67
Baseboard management
controller (BMC) with IPMI
firmware
ATI* Radeon* 7000M graphics
controller
LS* 1064 SAS controller
Light path diagnostics
Local service processor (BMC)
RS-485 interface for
communication with the
management module
Automatic server restart (ASR)
Serial over LAN (SOL)
Intelligent Platform Management
Interface (IPMI)
4 USB buses for communication
with keyboard, mouse, diskette
drive, and CD-ROM drive
Predictive Failure Analysis (PFA)
alerts:
SAS hard disk
Electrical Input: 12 V dc
Environment:
Air temperature:
Blade server on: 10° to 35° C (50°
to 95° F). Altitude: 0 to 914 m
(2998.69 ft)
Blade server on: 10° to 32° C (50°
to 95° F). Altitude: 914 m to 2134 m
(2998.69 ft to 7000 ft)
Blade server off: -40° to 60° C (-40°
to 140° F)
Humidity:
Blade server on: 8% to 80%
Blade server off: 5% to 80%
Size:
Height: 24.5 cm (9.7 inches)
Depth: 44.6 cm (17.6 inches)
Width: 2.9 cm (1.14 inches)
Maximum weight: 5.4 kg (12 lb)
