Using System Board Switches

The following illustration shows the location of switch block 2 (SW2).
Block 2 (SW2) Settings" on page 11
block.

Table 1. Switch Block 2 (SW2) Settings

Switch number
SW2
Intel® Server Compute Blade SBXD62 Installation and User's Guide
describes the function of each switch on the switch
Switch block 2 has eight switches:
•
1 - BIOS backup page
–
Off: the BIOS starts from the Primary BIOS page.
–
On: the BIOS starts from the backup BIOS page.
•
2 - Wake On LAN bypass
–
Off: Enabled
–
On: Disabled (default)
•
3 - Reserved
•
4 - Reserved
•
5 - Reserved
•
6 - Clear CMOS
–
Off: Disabled
–
On: Enabled
•
7 - Reserved
•
8 - Bypass power-on password during next server start
–
Off: Disabled (default)
–
On: Enabled
Table 1, "Switch
Switch block (SW2)
Description
