All DIMMs in a pair or group must be the same size, speed, type, technology, and
physical design. You can mix compatible DIMMs from different manufacturers.
•
All DIMMs must have the same speed. However, different pairs or groups of DIMMs
do not have to be of the same size, type, technology, and physical design.
•
Install only fully-buffered double-date rate dual-channel (FB-DDR2), PC2-4200,
registered SDRAM with ECC DIMMs. For a current list of supported DIMMs for the
blade server, see http://support.intel.com/support/.
•
Installing or removing DIMMs changes the configuration information for the blade
server. After installing or removing a DIMM, you must change and save the new
configuration information by using the Configuration/Setup Utility program. When
you restart the blade server, it displays a message indicating that the memory
configuration has changed. Start the Configuration/Setup Utility program and select
Save Settings (see
information).
To install a DIMM, complete the following steps:
1. Read the safety information beginning on page
page
2. Read the documentation that comes with the DIMMs.
3. Shut down the operating system, turn off the blade server, and remove the blade server
from the SBCE unit (see
Chassis SBCE" on page 16
4. Carefully lay the blade server on a flat, static-protective surface.
5. Open the blade server cover (see
instructions).
Intel® Server Compute Blade SBXD132 Installation and User's Guide
"Configuration/Setup Utility Menu Choices" on page 58
15.
"Removing the Blade Server from the Intel
for instructions).
DIMM connectors
2 (system board J142) and 4 (system board J144)
2 (Memory and I/O Expansion Blade J19) and 4 (Memory
and I/O Expansion Blade J21)
Retaining clip
vii and
"Opening the Blade Server Cover" on page 17
for more
DIMM
"Installation Guidelines" on
®
Blade Server
for
23
