Installing a SAS Hard Disk Drive
The blade server has two connectors on the system board for installing optional SFF SAS
hard disk drives.
Depending on the blade server model, at least one SAS hard disk drive might already be
installed. If the blade server is equipped with one SAS hard disk drive, you can install an
additional SAS hard disk drive. These two SAS hard disk drives can be used to implement
and manage a redundant array of independent disks (RAID) level-1 array. See
"Configuring a RAID Array" on page 63
The following illustration shows how to install a SAS hard disk drive.
Note: Do not install a SAS hard disk drive in SAS connector 1 (SAS ID 1) if you intend to also
install an optional standard-form-factor expansion card. The standard-form-factor
expansion card occupies the same area as the second hard disk drive.
To install a SAS hard disk drive, complete the following steps:
page
Chassis SBCE" on page 16
5. Locate SAS connector 0 (J136) or SAS connector 1 (J137).
6. If a standard-form-factor expansion card is installed in the SAS connector 1 location,
complete the following steps:
a. Remove the expansion card (see the illustration in
factor Expansion Card" on page
that secure the mounting bracket to the system board. Store the screws in a safe
place.
20
SAS ID 1
SAS ID 0
15.
Intel® Server Compute Blade SBXD132 Installation and User's Guide
for information about SAS RAID configuration.
vii
30) and its mounting bracket, and save the screws
®
"Installing a Standard-form-
