b. Install the SAS connector 1 drive tray. Secure the drive tray to the system board
with the screws from the option kit.
Caution:
7. Put the drive into the tray and push it, from the rear edge of the drive, into the
connector until the drive moves past the lever at the back of the tray.
If you have other options to install or remove, do so now; otherwise, go to
the Installation" on page

Removing a SAS Hard Disk Drive

The following illustration shows how to remove a SAS hard disk drive.
To remove a SAS hard disk drive, complete the following steps:

1. Read the safety information beginning on page

page
2. Shutdown the operating system, turn off the blade server, and remove the blade server
from the SBCE unit (see
Chassis SBCE" on page 16

3. Carefully lay the blade server on a flat, static-protective surface.

4. Open the blade server cover (see
instructions).
5. Locate SAS connector 0 (J136) or SAS connector 1 (J137). Slowly pull the blue lever
at the back of the hard disk drive tray away from the hard disk drive to disengage the
drive from its tray.
6. From the rear edge of the drive, slide the drive out of the SAS connector.
Intel® Server Compute Blade SBXD132 Installation and User's Guide
Do not press on the top of the drive. Pressing on the top might damage the
drive.
32.

SAS ID 1

Hard disk drive
release lever
SAS ID 0
15.
"Removing the Blade Server from the Intel

for instructions).

Hard disk

drive release

AF000934
lever
vii and
"Opening the Blade Server Cover" on page 17
"Completing
"Installation Guidelines" on
®

Blade Server

for
21
