Pin
1
2
3
4
The powered USB connector has the following pin functions:
Pin
1
2
3
4
5
6
7
8
See "Description of models" on page 4 for the cable part numbers.

Code page definitions

The SureMark printer has a resident character set that supports these code pages:
v Generic
v 437 (US)
v 850 (International) – Models TI1 and TI2 only
v 858 (International) – Models TI3, TI4, TI8, TG3, TG4, TF6 and TM6
v 860 (Portuguese)
v 863 (Canadian French)
v 865 (Norwegian)
Note: Code page 850 contains all characters from code page 858, except the
Four user-defined character sets for thermal printing and two character sets for
impact printing can be downloaded, if desired, using the 4610 Installation Utility
Diskette. See "Resources on the Internet" on page 44 for more information.
88
SureMark Printers User's Guide
Signal
Vbus (+5 V dc)
Minus data
Plus data
Ground
Signal
Ground (+24 V dc)
+24 V dc
Ground (Vbus)
Plus data
Minus data
Vbus +5 V dc
+24 V dc
Ground (+24 V dc)
EURO character.
August 24, 2004
