Recovery Mode
9.2. Recovery Mode
If the built-in web interface cannot be accessed, the unit can be reset by starting in Recovery Mode and
reinstalling the firmware.
Before You Begin
IMPORTANT
Use Recovery Mode only when the unit is unresponsive and the built-in web interface cannot be
accessed. Firmware updates should normally be carried out through the built-in web interface.
Procedure
To enter Recovery Mode
1. Press and hold MODE button during startup.
Figure 37. RESET button
2. Bolt Serial enters Recovery Mode.
To Reinstall the Firmware
1. To reinstalling the firmware, you need Anybus Firmware Manager II.
Download Anybus Firmware Manager II from www.anybus.com/support.
2. Install Anybus Firmware Manager II on your PC.
3. Launch Anybus Firmware Manager II and follow the instructions to reinstall the firmware.
