Anybus Wireless Bolt Serial
Setting
TCP Mode
TCP Server IP
Modbus Gateway Mode
TCP Port
Show Statistics
Page 34 of 60
Description
Select a TCP Mode from the dropdown menu:
Client: The Bolt Serial acts as a Client and establishes a connection to the TCP server.
Server: The Bolt Serial acts as a server and listens for incoming connections from the TCP Client.
When TCP Mode Client is selected, enter the TCP Server IP address.
When TCP Mode Server is enabled, select Modbus Gateway Mode to enable Modbus TCP to Modbus RTU
gateway functionality.
When TCP Mode is active, enter the TCP Port number. Default port: 5005
When Modbus Gateway Mode is active, the port automatically changes to Modbus TCP port 502.
Select Show Statistics to view Serial Rx and Tx statistics.
Buffer Size: The bytes in the queue, handled with in the order they were received. Used: Part of the buffer
used.
Total: Total size of the buffer.
Dropped: The number of dropped data packets.
Overrun: Occur when the buffer is full, but still tries to handle incoming data traffic.
Underrun: Occur when the incoming data traffic is at a lower speed than the outgoing data traffic.
Configure Settings in the Built-In Web Interface
