Operating Guide | VACON® 1000
Speed regulation resistor
l
Mechanical interlocking system: Standard in UL type drives and available as option +MMKI for IEC type drives. See
l
Interlocking System.
1
3
4
Figure 6: Controls and Indicators on the Door of the Control Cabinet
1 Line-up cabinet
3 HMI
5 Default indicators and controls
3.3.2 Power Cell Cabinet
The power cell cabinet contains the power cells and their accessories.
Danfoss A/S © 2024.12
5
6
Mode Switch Drive Drive
Local Remote Start Stop
2
3
Speed Emergency
Regulation Stop
2 Standalone cabinet
4 Mechanical interlocking system (+MMKI)
6 Optional indicators and controls
