11.2 Power Ratings and Dimensions
11.2.1 IEC Ratings
Table 31: Nominal Voltage 3000 V, 18-pulse, 3 Power Cells per Phase, 50 Hz
AC Drive type
VACON1000-ED-036-030+G2CE
VACON1000-ED-050-030+G2CE
VACON1000-ED-070-030+G2CE
VACON1000-ED-090-030+G2CE
VACON1000-ED-100-030+G2CE
VACON1000-ED-120-030+G2CE
VACON1000-ED-140-030+G2CE
VACON1000-ED-150-030+G2CE
VACON1000-ED-180-030+G2CE
154 | Danfoss A/S © 2024.12
2.3/2.4 kV input
3 kV input
3.3 kV input
4/4.2 kV input
4.8/5 kV input
6 kV input
6.3 kV input
6.6 kV input
6.9/7.2 kV input
8.4 kV input
10 kV input
11 kV input
11.4 kV input
12 kV input
12.47 kV input
13.2 kV input
13.8 kV input
Cabinet lights
Power cell bypass
UPS for control voltage (DC)
Low overload rating
110% (Variable
torque)
I [A] P [kVA]
L
36 180
50 250
70 360
90 460
100 510
120 620
140 720
150 770
180 930
8 kV
9 kV
10 kV
12 kV
14 kV
17 kV
18 kV
19 kV
20 kV
22 kV
25 kV
27 kV
28 kV
29 kV
30 kV
32 kV
34 kV
In the control cabinet
Automatic via IGBT, 1 ms bypass time (optional, +PPCB)
30 min running time
High overload rating Cabinet dimensions
150% (Constant
torque)
I [A] P [kVA] W [mm]
HD
26 130 1210
36 180 1210
51 260 1210
66 340 1610
73 370 1610
88 450 1610
102 530 1610
110 570 1910
132 680 1910
Specifications
Weight
[kg]
D [mm] H [mm]
1250 2796 2000
1250 2796 2050
1250 2796 2100
1250 2888 2850
1250 2888 2900
1250 2888 2950
1250 2888 3000
1250 2888 4350
1250 2888 4400
