Operating Guide | VACON® 1000
11.3 Internal Cables and Terminals
Table 47: Specifications for the Internal Power Cables and Terminals
Cable/busbar
Busbars for connecting power cells in se-
ries
Output neutral point cable
Output power cable
Danfoss A/S © 2024.12
Cable/busbar size Terminal type
2
30 mm N/A
2
40 mm N/A
2
90 mm N/A
2
160 mm N/A
9 AWG TLK10-8
5 AWG TLK25-8
2 AWG TLK35-8
2/0 AWG TLK70-8
3/0 AWG TLK95-8
4/0 AWG TLK120-8
250 kcmil TLK150-8
300 kcmil TLK185-10
400 kcmil TLK240-10
600 kcmil TLK400-12
750 kcmil TLK400-12
9 AWG TLK10-8
5 AWG TLK25-8
2 AWG TLK35-8
2/0 AWG TLK70-8
3/0 AWG TLK95-8
4/0 AWG TLK120-8
250 kcmil TLK150-8
300 kcmil TLK185-10
400 kcmil TLK240-10
600 kcmil TLK400-12
750 kcmil TLK400-12
Screw type Tightening torque (Nm)
M6×16 8
M6×16 8
M6×16 8
M8×25 15
M8×25 15
M8×25 15
M8×25 15
M8×25 15
M8×25 15
M8×25 15
M8×25 15
M10×35 40
M10×35 40
M10×35 40
M10×35 40
M8×25 15
M8×25 15
M8×25 15
Nut M8 15
Nut M8 15
Nut M8 15
Nut M8 15
M10×35 40
M10×35 40
M10×35 40
M10×35 40
