Operating Guide | VACON® 1000
Table 36: Nominal Voltage 10000 V, 48-pulse, 8 Power Cells per Phase, 50 Hz
AC Drive type
VACON1000-ED-036-100+G2CE
VACON1000-ED-050-100+G2CE
VACON1000-ED-070-100+G2CE
VACON1000-ED-090-100+G2CE
VACON1000-ED-100-100+G2CE
VACON1000-ED-120-100+G2CE
VACON1000-ED-140-100+G2CE
VACON1000-ED-150-100+G2CE
VACON1000-ED-180-100+G2CE
VACON1000-ED-190-100+G2CE
VACON1000-ED-215-100+G2CE
VACON1000-ED-250-100+G2CE
VACON1000-ED-305-100+G2CE
VACON1000-ED-350-100+G2CE
VACON1000-ED-438-100+G2CE
VACON1000-ED-560-100+G2CE
VACON1000-ED-680-100+G2CE
Table 37: Nominal Voltage 11000 V, 54-pulse, 9 Power Cells per Phase, 50 Hz
AC Drive type
VACON1000-ED-036-110+G2CE
VACON1000-ED-050-110+G2CE
VACON1000-ED-070-110+G2CE
VACON1000-ED-090-110+G2CE
VACON1000-ED-100-110+G2CE
VACON1000-ED-120-110+G2CE
VACON1000-ED-140-110+G2CE
VACON1000-ED-150-110+G2CE
VACON1000-ED-180-110+G2CE
VACON1000-ED-190-110+G2CE
VACON1000-ED-215-110+G2CE
158 | Danfoss A/S © 2024.12
Low overload rating High overload rating
110% (Variable 150% (Constant
torque) torque)
I [A] P [kVA] I [A]
L HD
36 620 26
50 860 36
70 1210 51
90 1550 66
100 1730 73
120 2070 88
140 2420 102
150 2590 110
180 3110 132
190 3290 139
215 3720 157
250 4330 183
305 5280 223
350 6060 256
438 7580 321
560 9690 410
680 11770 498
Low overload rating High overload rating
110% (Variable 150% (Constant
torque) torque)
I [A] P [kVA] I [A]
L HD
36 680 26
50 950 36
70 1330 51
90 1710 66
100 1900 73
120 2280 88
140 2660 102
150 2850 110
180 3420 132
190 3610 139
215 4090 157
Cabinet dimensions
P [kVA] W [mm] D [mm]
450 3410 1250
620 3410 1250
880 3410 1250
1140 3910 1250
1260 3910 1250
1520 3910 1250
1760 3910 1250
1900 4660 1250
2280 4660 1250
2400 4660 1250
2710 4660 1250
3160 6560 1400
3860 6560 1400
4430 6760 1400
5550 9810 1400
7100 10610 1400
8620 11010 1400
Cabinet dimensions
P [kVA] W [mm] D [mm]
490 3410 1250
680 3410 1250
970 3410 1250
1250 3910 1250
1390 3910 1250
1670 3910 1250
1940 3910 1250
2090 4660 1250
2510 4660 1250
2640 4660 1250
2990 4660 1250
AQ363633621020en-000401 / 172F3117D
Specifications
Weight
[kg]
H [mm]
2796 4100
2796 4400
2796 4700
2888 6250
2888 6550
2888 6850
2888 7250
2888 10100
2888 10400
2888 10700
2888 11100
2796 11600
2796 13100
2796 14400
2796 18200
2796 21900
2796 25350
Weight
[kg]
H [mm]
2796 4400
2796 4800
2796 5200
2888 6550
2888 6850
2888 7150
2888 7550
2888 10600
2888 10900
2888 11200
2888 11500
