Operating Guide | VACON® 1000
1
2
Figure 18: Switches and Indicators on the Manual Bypass Cabinet
1 Switch QS41
3 Indicators Variable frequency/Power frequency
1
2
3
Figure 19: Manual Bypass Cabinet
1
Top entry for cabling
3 Output terminals
5 Input terminals
7 Bottom entry for cabling
30 | Danfoss A/S © 2024.12
3
4
2 Switch QS42/QS43
4 Light switch (controls the light inside the cabinet)
4
5
6
7
2
Surge arrester (optional)
4 Isolation switch (single)
6 Isolation switch (double)
Product Overview
AQ363633621020en-000401 / 172F3117D
