Display Name
Laser Power
Profile Average Reflectance
Current Profile Rate (Hz)
Profile Rate Max (Hz)
Profile Exposure Time (in us)
Reflectance Threshold
HDR Response Mode
One Knee Point, Mid
One Knee Point, High
HDR Response Factor
FIR Size
Gamma Correction
Gain
Noise Reduction Level
HFPN Mode

Info-Profile Rate Optimization Features

This category indicates the features that can be modified to reach the maximum profile rate (Profile Rate Max
feature) achievable by the sensor given the current configuration.
Display Name
Measurement AOI Height
Optimized
Decrease AOI Height
Measurement AOI Width
Optimized
Decrease AOI Width
Z-Trak Family of 3D Sensors
Feature & Values
laserPower
profileAvgReflectance
profileRate
profileRateMax
ExposureTime
peakDetectorReflectanceThreshold
hdrResponseMode
Off
OneKneeMid
OneKneeHigh
hdrResponseFactor
firSize
11
9
7
5
gammaCorrection
Gain
noiseReductionLevel
hfpnMode
Feature & Values
aoiHeightOptimization
aoiWidthOptimization
Description
User set laser power setting for when the feature
laserControlMode=Manual.
Reads the average reflectance of the last profile.
Specifies the profile rate of the sensor, in Hz.
Maximum profile rate the sensor is capable of reaching using
the current configuration. Refer to the Info-Profile Rate
Optimization category to determine how to increase the
Profile Rate Max.
Sets the exposure time (in microseconds).
Value which identifies the minimum reflectance a peak must
have to be considered.
Sets the state of the multislope response mechanism on the
sensor.
Off Disables the hdrResponseMode feature.
One Knee Point, Mid Position (~70%).
One Knee Point, High Position (~90%).
HDR Response Factor.
Sets the size of the FIR (Finite Impulse Response).
fir11 FIR size 11.
fir9 FIR size 9.
fir7 FIR size 7.
fir5 FIR size 5.
Sets the gamma correction factor (i.e. inverse gamma). The
gamma correction is applied as an exponent to the original
pixel value. (Default value: 1, max value: 1, min value: 0.001,
increments: 0.001)
Analog gain setting of the image sensor.
Decreases noise level to improve profile. Used in conjunction
with Gain.
Enables or disables horizontal fixed pattern noise correction.
Description
Indicates how to modify the Measurement AOI
Height feature to increase the maximum profile rate
achievable by the sensor, if not optimized.
Optimized Optimized.
decreaseAOIHeight Decreasing the Measurement AOI Height will
increase the maximum profile rate the sensor can
achieve.
Indicates how to modify the Measurement AOI Width
feature to increase the maximum profile rate
achievable by the sensor, if not optimized.
Optimized Optimized.
decreaseAOIWidth Decreasing the Measurement AOI Width will
increase the maximum profile rate the sensor can
achieve.
Teledyne Vision Solutions
Device
Version
1.00
DFNC
1.00
DFNC
1.00
DFNC
1.00
DFNC
1.00
DFNC
1.00
DFNC
1.00
DFNC
1.00
DFNC
1.00
DFNC
1.00
DFNC
1.20
1.20
DFNC
1.20
DFNC
Device
Version
1.00
DFNC
1.00
DFNC
Operational Reference • 83
