Display Name
Trigger Start Input Line Activation
Falling Edge
Rising Edge
Any Edge
Level High
Trigger Overlap
ReadOut
Trigger Delay
Scan Trigger Stop Source
Multi Sensor Sync
Timer 1 End Event
Counter 1 End Event
Trigger Stop Input Line Activation
Rising Edge
Level High
Profile Trigger Maximum Frequency
Profile Trigger Frequency
Scan Trigger Status
Inactive
Delay Active
Z-Trak Family of 3D Sensors
Feature & Values
TriggerActivation
TriggerOverlap
Off
TriggerDelay
triggerStopSource
Line 3
Line 4
MultiSensorSync
triggerStopActivation
profileTriggerMaxFrequency
profileTriggerFrequency
frameBurstState
Active
Description
Selects the activation mode for the Trigger Input. This is
applicable only for external line inputs.
FallingEdge
The trigger is considered valid when the line source signal
goes from high to low.
RisingEdge
The trigger is considered valid when the line source signal
goes from low to high.
AnyEdge
The trigger is considered valid for any transition on the line
source signal.
LevelHigh
The trigger is considered valid while the line source signal is
high.
Selects if a new trigger will be accepted (or latched) while the
previous one is still being processed.
Off
No trigger overlap is permitted.
ReadOut
Profile Trigger is accepted immediately after the start of the
image sensor readout.
Specifies the delay before the profile integration starts or the
scan starts.
For profile trigger mode, this value specifies the delay in µSec.
For scan trigger modes, this value specifies the delay in the
number of profiles to skip before starting the scan.
Variable scan stops when the trigger stop source is activated.
Line3
The variable scan is stopped when Line 3 is activated.
Line4
The variable scan is stopped when Line 4 is activated.
The variable scan is stopped when the Multi Sensor Sync stop
message is assessed.
Timer1End
The variable scan is stopped by a Timer 1 End event.
Counter1End
The variable scan is stopped by a Counter 1 End event.
Select the activation mode for the "Trigger Stop Source". This
is applicable only for external line inputs.
RisingEdge
The trigger is considered valid when the line source signal
goes from low to high.
LevelHigh
The trigger is considered valid while the line source signal is
high.
Maximum number of profile triggers accepted per second at
current exposure time.
Reads the number of profile triggers sent to
"TriggerSelector=Profile Trigger" per second.
Indicates the current status of Scan Trigger signal
Inactive
The scan is waiting for a trigger or the grab to start.
Active
The scan is active and acquiring profiles.
DelayActive
The scan trigger has been activated and is delayed by the
number of profiles specified by the Trigger Delay feature.
Teledyne Vision Solutions
Device
Version
1.00
1.00
1.00
1.00
DFNC
1.00
1.00
DFNC
1.00
DFNC
1.00
DFNC
Operational Reference • 97
