Profiler Management Category

The Profiler Management category provides profiler information and diagnostics. This information is mostly read-
only; GigE Vision applications retrieve it to identify the profiler along with its characteristics.

Profiler Management Features

Display Name
Product Model
Firmware Version
Serial Number
Device User ID
Power-up configuration
Factory Setting
UserSet1
UserSet2
User Set Selector
Factory Setting
UserSet 1
UserSet 2
80 • Operational Reference
Feature Name & Values
DeviceModelName
DeviceFirmwareVersion
DeviceSerialNumber
DeviceUserID
UserSetDefault
Default
UserSet1
UserSet2
UserSetSelector
Default
UserSet1
UserSet2
Description
Displays the device model name.
Displays the currently loaded firmware version number.
Firmware files have a unique number and have the .cbf file
extension.
Displays the factory set serial number of the device.
Feature to store a user-programmable identifier of up to 15
characters. The default factory setting is the device serial
number
Specifies the profile sensor configuration set to load and make
active on power-up or reset. The configuration sets are stored in
non-volatile memory of the device.
Select the Factory Setting values as the Power-up
Configuration.
Select the user defined configuration UserSet 1 as the Power-
up Configuration.
Select the user defined configuration UserSet 2 as the Power-
up Configuration.
Selects the configuration set to load feature settings from or
save current feature settings to. The Factory set contains
default camera feature settings. User configuration sets contain
feature settings previously saved by the user.
Select the default device feature settings saved by the Factory.
Select the User defined Configuration space UserSet1 to save
to or load from features settings previously saved by the user.
Select the User defined Configuration space UserSet2 to save
to or load from features settings previously saved by the user.
Teledyne Vision Solutions
Device
Version
1.00
1.00
1.00t
1.00
1.00
1.00
Z-Trak Family of 3D Sensors
