Format Features

Proposes device output type and 3D data types, along with measurement unit options.
Display Name
Device Output Type
Linescan3D
Linescan 1D (mono 16-bit)
Areascan
3D Data Type
UniformX Z
XZRW
Measurement Units
Micrometer
Millimeter
Inch/1000
Z Scaler
X Scaler
Pixel Format
Monochrome 8-Bit
Monochrome 10-Bit
3D Coordinate Z (16-bit)
3D Coordinate XZ (32-bit)
3D Coordinate XZRW
(64-bit)
Monochrome 16-Bit
90 • Operational Reference
Feature & Values
DeviceScanType
Linescan3D
Scan3dOutputMode
XZ CalibratedAC
CalibratedACRW
Scan3dDistanceUnit
heightScaler
widthScaler
PixelFormat
Coord3D_C16
Coord3D_AC16
Coord3D_ACR016
Description
Selects the output type of the device.
Device outputs lines of 3D profiles.
Linescan Device outputs lines of 3D profiles in Mono16 format. For
software packages not compliant with GeniCam 3D standard
output formats.
Areascan Device outputs 2D area scan images.
Selects 3D output data format (default is UniformX Z).
RectifiedC Each profile consists of calibrated Z values in a 16-bit data
format. The Z values have been resampled to a uniform
sampling pattern in the X direction.
Each profile consists of calibrated X and Z values in a 32 bit
data format.
Each profile consists of calibrated X, Z, R (reflectance) and W
(peak width) values in a 64-bit data format. The first two 16-bit
fields are as the calibrated XZ. The third and fourth 16-bit fields
contain the R and W data.
Sets the measurement units for the profile X and Z data (default
is Micrometer).
Micrometer All X and Z values are in micrometer units.
Millimeter All X and Z values are in millimeter units.
Inch_1000 All X and Z values are in thousands of an inch (mil).
Scaling factor to convert Z values to the units specified by
Measurement Units.
Scaling factor to convert X values to the units specified by
Measurement Units.
Pixel formats as defined by the GeniCam standard.
Mono8 Monochrome 8-Bit data format. Only available in Areascan
mode.(Z-Trak2)
Mono10 Monochrome 10-Bit data format. Only available in Areascan
mode. (LP2C)
3D Coordinate: Z position (16-Bit)
3D Coordinate: X and Z positions stored
in a 32-Bit value.
3D Coordinate: X and Z positions, Reflectance and peak Width
stored in a 64-bit value.
Mono16 Mono16: Monochrome 16-Bit
Teledyne Vision Solutions
Device
Version
1.00
DFNC
1.00
1.00
DFNC
1.00
DFNC
1.00
DFNC
1.00
1.20
Z-Trak Family of 3D Sensors
