Package Contents
•
One ADSL Barricade.
•
One Power adapter.
•
One RJ-45 Ethernet cable (straight-through type).
•
One RJ-11 Standard phone/DSL line cable.
•
One USB Cable (Optional).
•
Installation utility and Documentation CD.
•
Quick Installation Guide.
Hardware Description
Front Panel
The front panel contains lights called LEDs that indicate
the status of the unit.
LED
PW
(Power)
LK
(Link)
G
ETTING TO
ADSL B
COLOR
FUNCTION
Green
On: Unit is powered on.
Off: Unit is powered off.
Green
Flashing when ADSL data activity occurs.
May be steady when data traffic is heavy.
Table 1. Front Panel and LEDs
K
NOW
ARRICADE
5
