USER GUIDE
SMCWBR14-3GN
802.11b/g/n Wireless AP/Router

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMCWBR14-3GN and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks SMCWBR14-3GN

Summary of Contents for SMC Networks SMCWBR14-3GN

  • Page 1 USER GUIDE SMCWBR14-3GN 802.11b/g/n Wireless AP/Router...
  • Page 3 802.11b/g/n wireless AP/Router User Guide 20 Mason January 2009 Irvine, CA 92618 Pub. # 149100043400A Phone: (949) 679-8000 E012009-AP-R01...
  • Page 4 Information furnished by SMC Networks, Inc. (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.
  • Page 5 Limited Warranty Limited Warranty Statement: SMC Networks, Inc. (“SMC”) warrants its products to be free from defects in workmanship and materials, under normal use and service, for the applicable warranty term. All SMC products carry a standard 90-day limited warranty from the date of purchase from SMC or its Authorized Reseller.
  • Page 6 * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase. SMC Networks, Inc. 20 Mason Irvine, CA 92618...
  • Page 7 Compliances Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 8 Modulation Interface Brand Name Model Name FCC ID Technology HSDPA USB HUAWEI E220 QISE220 Modem (3G Card) GSM/UMTS 3G Card Sony Ericsson MD300 PY7F3232021 3G Card Band Luxe C100S UZI-C100 EC Conformance Declaration Marking by the above symbol indicates compliance with the Essential Requirements of the R&TTE Directive of the European Union (1999/5/EC).
  • Page 9 This device is intended for use in the following European Community and EFTA countries: Czech Estonian Käesolevaga kinnitab SMC seadme Radio LAN device vastavust Eesti direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. English Hereby, SMC, declares that this Radio LAN device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
  • Page 10 Lithuanian Maltese Malti Spanish Por medio de la presente SMC declara que el Radio LAN device Español cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE Polish Polski Portuguese SMC declara que este Radio LAN device está conforme com os Português requisitos essenciais e outras disposições da Directiva 1999/5/CE.
  • Page 11 About This Guide Purpose wireless AP/Router This guide details the hardware features of the , including its physical and performance-related characteristics, and how to install the device and use its configuration software. Audience This guide is for PC users with a working knowledge of computers. You should be familiar with Windows operating system concepts.
  • Page 12 viii...

  • Page 13: Table Of Contents

    Table of Contents Chapter 1: Introduction Package Checklist Hardware Description LED Indicators Ethernet RJ-45 Ports 3G Modem USB Port Power Socket Reset Button WPS Button Chapter 2: Installation Router Mode AP Mode Chapter 3: Network Planning Internet Gateway Router LAN Access Point Wireless Bridge Chapter 4: Initial Configuration Using the Setup Wizard...
  • Page 14 Contents Backup WAN Common Settings DHCP Static IP PPPoE 5-11 PPTP 5-13 L2TP 5-14 Bigpond 5-16 LAN Setting 5-17 QoS Setting 5-18 Wireless Settings 5-20 Basic Settings 5-21 Advanced Settings 5-23 WLAN Security 5-25 MAC Access Control Lists 5-35 Wi-Fi Protected Setup (WPS) 5-37 Routing 5-40...
  • Page 15 Appendix A: Troubleshooting Appendix B: Specifications Appendix C: License Information The GNU General Public License Glossary Index...
  • Page 16 Contents...

  • Page 17: Chapter 1: Introduction

    Chapter 1: Introduction The SMCWBR14-3GN wireless AP/Router is an IEEE 802.11n wireless gateway router that connects your Internet access device (cable or ADSL modem) to your PC or local area network, or to its own secure wireless network. The wireless AP/Router can be automatically configured with other Wi-Fi Protected Setup (WPS) devices by simply pressing its WPS button.

  • Page 18: Hardware Description

    Introduction Hardware Description Power Socket Security Slot Reset Button Ethernet WAN 3G Modem RJ-45 Port USB Port Ethernet LAN RJ-45 Ports Figure 1-1. Rear Panel...
  • Page 19 Hardware Description Antennas 3G Button WPS Button WLAN Button Figure 1-2. Front Panel AP/Router Mode Switch Figure 1-3. Bottom Panel...

  • Page 20: Led Indicators

    Introduction LED Indicators The wireless AP/Router includes nine status LED indicators, as described in the following figure and table. LAN Link/Activity WAN Link/Activity Power 802.11n Link/Activity WPS Link/Activity 3G Link Figure 1-4. LED Indicators Status Description POWER On Green Indicates that the system is working normally. On/Flashing Green Indicates a valid link on the WAN Ethernet port.

  • Page 21: Ethernet Rj-45 Ports

    Hardware Description Ethernet RJ-45 Ports The wireless AP/Router has the following RJ-45 ports: • The four RJ-45 LAN ports are for connections to PCs or to a 10/100 Mbps. • The RJ-45 WAN port is for connection to a DSL or cable modem, or to a LAN or other device that provides your Internet access.
  • Page 22 Introduction...

  • Page 23: Chapter 2: Installation

    Chapter 2: Installation The wireless AP/Router has two basic operating modes that can be set through the switch on the bottom panel of the device: • Router Mode — Normal gateway mode that connects a wired LAN and wireless clients to an Internet access device, such as a cable or DSL modem. This is the factory set default mode.

  • Page 24: Ap Mode

    Installation To connect the wireless AP/Router in Router Mode for use as an Internet gateway, follow these steps: Connect an Ethernet cable from the wireless AP/Router’s WAN port to your Internet connected cable or ADSL modem. Connect an Ethernet cable from the wireless AP/Router’s LAN port to your PC. Alternatively, you can connect to a workgroup switch to support multiple users.
  • Page 25 AP Mode Figure 2-2. AP Mode Connection To connect the wireless AP/Router for use as an access point, follow these steps: Using Ethernet cables, connect the wireless AP/Router’s LAN and WAN ports to PCs or a LAN switch. Power on the wireless AP/Router by connecting the AC power adapter and plugging it into a power source.
  • Page 26 Installation...

  • Page 27: Chapter 3: Network Planning

    Chapter 3: Network Planning The wireless AP/Router is designed to be very flexible in its deployment options. It can be used as an Internet gateway for a small network, or as an access point to extend an existing wired network to support wireless users. It also supports use as a wireless bridge to connect two wired LANs.

  • Page 28: Lan Access Point

    Network Planning The private local network, connected to the LAN port or wireless interface, provides a Dynamic Host Configuration Protocol (DHCP) server for allocating IP addresses to local PCs and wireless clients, and Network Address Translation (NAT) for mapping the multiple "internal" IP addresses to one "external" IP address. The public external network, connected to the WAN port, supports DHCP client, Point-to-Point Protocol over Ethernet (PPPoE) and static IP for connection to an Internet service provider (ISP) through a cable or DSL modem.

  • Page 29: Wireless Bridge

    Wireless Bridge Wireless Bridge The IEEE 802.11 standard defines a Wireless Distribution System (WDS) for bridge connections between access points. The wireless AP/Router can use WDS to forward traffic on links between units. A single WDS bridge link can be specified for the WLAN1 interface. One end of a link must be configured as the “WDS Parent”...
  • Page 30 Network Planning...

  • Page 31: Chapter 4: Initial Configuration

    Chapter 4: Initial Configuration The wireless AP/Router offers a user-friendly web-based management interface for the configuration of all the unit’s features. Any PC directly attached to the unit can access the management interface using a web browser, such as Internet Explorer (version 6.0 or above).

  • Page 32: Using The Setup Wizard

    Initial Configuration Using the Setup Wizard There are only a few basic steps you need to set up the wireless AP/Router and provide a connection for network access for other wireless stations. The Setup Wizard takes you through configuration procedures for the general network settings.
  • Page 33 Using the Setup Wizard WAN Configuration – Specifies the Internet connection parameters for the wireless AP/Router’s WAN port. Click Next after completing the setup. The interface provides the facility for Dual WAN connections for purposes of backing up the main internet connection. Figure 4-4.

  • Page 34: Common Settings

    Initial Configuration Common Settings The common settings for each WAN Connection mode are identical and are described in the section below. Figure 4-5. Common Settings WAN Ethernet MAC — Some ISPs limit Internet connections to a specified MAC address of one PC. This setting allows you to manually change the MAC address of the wireless AP/Router's WAN interface to match the PC's MAC address provided to your ISP for registration.

  • Page 35: Static Ip

    Using the Setup Wizard Static IP Configures a static IP for the WAN port. The following example shows the dual WAN function enabled using 3G as a secondary WAN connection. Figure 4-6. Setup Wizard - WAN Static IP • IP Address: The IP address of the wireless AP/Router. Valid IP addresses consist of four decimal numbers, 0 to 255, separated by periods.

  • Page 36: Dhcp

    Initial Configuration DHCP Enables DHCP for the WAN port. The dual WAN option is disabled in the following example. Figure 4-7. Setup Wizard - WAN DHCP PPPoE Enable the wireless AP/Router IP address to be assigned automatically from an Internet service provider (ISP) through an ADSL modem using Point-to-Point Protocol over Ethernet (PPPoE).
  • Page 37 Using the Setup Wizard • PPPoE Password: Sets a PPPoE password for the WAN port. (Default: PPPOE_PASSWORD; Range: 1~32 characters) Enables a 3G/3.5G wide-area wireless cellular link on the WAN port using an optional USB modem. Note: To use this option you need to first connect a 3G/3.5G USB modem to the USB port on the back of the unit and have registered an account with a cellular operator.
  • Page 38 Initial Configuration The following cautionary message will appear each time you save your settings. Figure 4-10. Setup Wizard - WAN 3G PIN Code Warning An unauthenticated connection will display the message ‘Not dial yet’ beneath the PIN code, as shown in the following illustration. However if you have previously entered the correct PIN code followed by an incorrect PIN code, your connection will wait ten seconds and automatically default to the correct PIN code for authentication.
  • Page 39 Using the Setup Wizard • Pin Code: Specifies a PIN code number that corresponds with that set on your 3G/ 3.5G USB modem and displays the status of the 3G connection. - Not dial yet: Indicates that the PIN code has not been entered or is incorrect. - Authenticated successfully: Indicates that the 3G connection has authenticated successfully.
  • Page 40 Initial Configuration • Default Gateway: The IP address of the gateway router for the wireless AP/ Router, which is used if the requested destination address is not on the local subnet. • PPTP Username: Sets the PPTP user name for the WAN port. (Default: PPTP_USERNAME;...
