Configuring the ADSL Barricade's Interfaces with RIP
RIP version 2 is the preferred selection because it supports
classless IP addresses (which are used to create subnets)
and other features. Select [RIP2] if all other routing devices on
the autonomous network support this version of the protocol.
6. Click [Add]. The new RIP entry will display in the table.
7. Click the [Enable] radio button to enable the RIP feature.
Note: If you disable the RIP feature, the interface settings
you have configured will remain available for future
activation.
8. When you are finished defining RIP interfaces, click [Submit].
A page appears to confirm your changes.
9. Click the [Admin] tab, and then click [Commit & Reboot]
in the task bar.
10. Click [Commit] to save your changes to the permanent
memory.
Note: You can delete an existing RIP entry by clicking
in the [Action] column.
