Field
Gateway Address
Status
Action

Adding IPoA Interfaces

Follow these instructions to add an IPoA interface:
1. Display the [IP over ATM (IPoA) Configuration] page and click
[Add]. The [IPoA Interface – Add] page appears, as shown in
Figure 43.
Description
This is the external IP address that the ADSL Barricade
communicates with via the IPoA interface to gain
access to the Internet. This is typically an ISP server.
A green or red ball will appear to indicate that the interface
is currently up or down, respectively. You cannot manually
enable or disable the interface; a down interface may
indicate a problem with the DSL connection.
This field displays icons you can click on to edit (
delete ( ) the associated IPoA interface.
Figure 43. PoA Interface – Add Page
Adding IPoA Interfaces
) or
121
