Field
Security Protocol:
Login Name:

Adding a PPP Interface Definition

If you intend to use more than one type of service from your ISP,
the device can be configured with multiple PPP interfaces, each
with unique logon and other properties.
Follow this procedure to define properties for a PPP interface:
1. From the [Point to Point Protocol (PPP) Configuration Page],
click [Add]. The [PPP Interface – Add] page appears, as
shown in Figure 38.
Adding a PPP Interface Definition
Description
This field indicates the type of PPP security your
ISP uses:
[PAP] (Password Authentication Protocol)
[CHAP] (Challenge Handshake Authentication
Protocol).
This is the name you use to log in to your ISP each
time this PPP connection is established.
Figure 38. PPP Interface – Add Page
109
