Configuration Options

For advanced management capability, the on-board management
agent provides a menu-driven system configuration program. This
program can be accessed by a direct connection to the serial port
on the rear panel (out-of-band), or by a Telnet connection over the
network (in-band).
The management agent is based on SNMP (Simple Network
Management Protocol). This SNMP agent permits the switch to be
managed from any PC in the network using in-band management
software (such as SMC's EliteView).
The management agent also includes an embedded HTTP Web
agent. This Web agent can be accessed using a standard Web
browser from any computer attached to the network.
The system configuration program and the SNMP agent support
management functions such as:
• Enable/disable any port
• Set the communication mode for any port
• Configure SNMP parameters
• Configure VLANs or multicast filtering
• Display system information or statistics
• Configure the switch to join a Spanning Tree
• Download system firmware
• Restart the system
S
WITCH
C
HAPTER
M
ANAGEMENT
1
1-1
