Alinx ARTIX UltraScale+ AXAU15 User Manual page 21

PIN29 GND
PIN31 225_TX0_N
PIN33 225_TX0_P
PIN35 GND
PIN37 225_TX1_N
PIN39 225_TX1_P
PIN41 GND
PIN43 225_TX2_N
PIN45 225_TX2_P
PIN47 GND
PIN49 225_TX3_N
PIN51 225_TX3_P
PIN53 GND
PIN55 226_TX0_N
PIN57 226_TX0_P
PIN59 GND
PIN61 226_TX1_N
PIN63 226_TX1_P
PIN65 GND
PIN67 226_TX2_N
PIN69 226_TX2_P
PIN71 GND
PIN73 226_TX3_N
PIN75 226_TX3_P
PIN77 GND
PIN79 226_CLK0_P
21 / 40
- GND PIN30
AA4 1.2V PIN32
AA5 1.2V PIN34
- GND PIN36
W4 1.2V PIN38
W5 1.2V PIN40
- GND PIN42
U4 1.2V PIN44
U5 1.2V PIN46
- GND PIN48
R4 1.2V PIN50
R5 1.2V PIN52
- GND PIN54
N4 1.2V PIN56
N5 1.2V PIN58
- GND PIN60
L4 1.2V PIN62
L5 1.2V PIN64
- GND PIN66
J4 1.2V PIN68
J5 1.2V PIN70
- GND PIN72
G4 1.2V PIN74
G5 1.2V PIN76
- GND PIN78
P7 1.2V PIN80
AXAU15 User Manual
GND -
225_RX0_N Y1
225_RX0_P Y2
GND -
225_RX1_N V1
225_RX1_P V2
GND -
225_RX2_N T1
225_RX2_P T2
GND -
225_RX3_N P1
225_RX3_P P2
GND -
226_RX0_N M1
226_RX0_P M2
GND -
226_RX1_N K1
226_RX1_P K2
GND -
226_RX2_N H1
226_RX2_P H2
GND -
226_RX3_N F1
226_RX3_P F2
GND -
226_CLK0_N P6
www.alinx.com
GND
1.2V
1.2V
GND
1.2V
1.2V
GND
1.2V
1.2V
GND
1.2V
1.2V
GND
1.2V
1.2V
GND
1.2V
1.2V
GND
1.2V
1.2V
GND
1.2V
1.2V
GND
1.2V
