Alinx ARTIX UltraScale+ AXAU15 User Manual page 18

PIN9 GND
PIN11 B65_L14_N
PIN13 B65_L14_P
PIN15 B65_L17_N
PIN17 B65_L17_P
PIN19 GND
PIN21 B65_L16_N
PIN23 B65_L16_P
PIN25 B65_L10_N
PIN27 B65_L10_P
PIN29 GND
PIN31 B65_L11_N
PIN33 B65_L11_P
PIN35 B65_L2_N
PIN37 B65_L2_P
PIN39 GND
PIN41 B65_L23_N
PIN43 B65_L23_P
PIN45 B65_L3_N
PIN47 B65_L3_P
PIN49 GND
PIN51 B65_L20_N
PIN53 B65_L20_P
PIN55 B65_L6_N
PIN57 B65_L6_P
PIN59 GND
PIN61 B65_L1_N
PIN63 B65_L1_P
PIN65 B84_L6_N
PIN67 B84_L6_P
PIN69 GND
PIN71 FPGA_TCK
PIN73 FPGA_TDI
PIN75 FPGA_TMS
PIN77 FPGA_TDO
PIN79 NC
18 / 40
- GND
U25 1.8V
T25 1.8V
P26 1.8V
P25 1.8V
- GND
V26 1.8V
U26 1.8V
W26 1.8V
W25 1.8V
- GND
W23 1.8V
V23 1.8V
U22 1.8V
U21 1.8V
- GND
P19 1.8V
N19 1.8V
U20 1.8V
T20 1.8V
- GND
P21 1.8V
P20 1.8V
W20 1.8V
W19 1.8V
- GND
V19 1.8V
U19 1.8V
AB16 3.3V
AB15 3.3V
- GND
AE12 1.8V
AB12 1.8V
AB10 1.8V
Y10 1.8V
- Null
AXAU15 User Manual
PIN10 GND
PIN12 B65_L24_N
PIN14 B65_L24_P
PIN16 B65_L15_N
PIN18 B65_L15_P
PIN20 GND
PIN22 B65_L19_N
PIN24 B65_L19_P
PIN26 B65_L5_N
PIN28 B65_L5_P
PIN30 GND
PIN32 B65_L12_N
PIN34 B65_L12_P
PIN36 B65_L8_N
PIN38 B65_L8_P
PIN40 GND
PIN42 B65_L21_N
PIN44 B65_L21_P
PIN46 B65_L4_N
PIN48 B65_L4_P
PIN50 GND
PIN52 B65_L9_N
PIN54 B65_L9_P
PIN56 B65_L7_N
PIN58 B65_L7_P
PIN60 GND
PIN62 B84_L2_N
PIN64 B84_L2_P
PIN66 B84_L1_N
PIN68 B84_L1_P
PIN70 GND
PIN72 B84_L3_N
PIN74 B84_L3_P
PIN76 B84_L4_N
PIN78 B84_L4_P
PIN80 NC
- GND
N22 1.8V
N21 1.8V
P24 1.8V
N24 1.8V
- GND
R23 1.8V
R22 1.8V
T23 1.8V
T22 1.8V
- GND
W24 1.8V
V24 1.8V
Y26 1.8V
Y25 1.8V
- GND
R21 1.8V
R20 1.8V
V22 1.8V
V21 1.8V
- GND
AA25 1.8V
AA24 1.8V
Y23 1.8V
Y22 1.8V
- GND
AF13 3.3V
AE13 3.3V
AF15 3.3V
AF14 3.3V
- GND
AE15 3.3V
AD15 3.3V
AD14 3.3V
AD13 3.3V
- Null
