Rea® Azalea®
8.5 Electrical system — Models equipped
with electric tilt and backrest
U in 100–240 Voltage, AC, 50/60 Hz (AC =
Voltage
Alternating current), Battery (Lead acid) DC
supply
24V (DC=Direct Current)
Maximum I in max. 5 Ampere (battery = max 1,3
current input Ampere)
Intermittent
(periodic
10 % 2 min ON / 18 min OFF
motor
operation)
Protection
class
CLASS II equipment
Applied Part complying with the specified
requirements for protection against
electrical shock according to IEC60601-1.
The control unit, external power supply,
motors and hand controls are protected
according to IPx6. See label and label on
each electric device for correct IP class. The
Degree of
lowest IP-classification decides the overall
protection
classification of the system.
IPx6- The system is protected against water
projected from any direction (not high
pressure).
Approximate time of 6 hours using the
Charging time
charging via integrated charged.
The battery must be stored in an appropriate storage
room to avoid direct sunlight. For full details contact
your Invacare authorized provider.
8.6 Electromagnetic compliance (EMC)
General information
Products with electronic equipment needs to be installed and
used according to the EMC information in this user manual.
WARNING!
Portable and mobile communications equipment
can affect the operation of this product.
— In the case of the product moves itself
unintentionally while being submitted to
Electromagnetic interference, then stop
immediately using the product and send it to
check b y a qualified technician.
This product has been tested and complies with the EMC limits
specified by IEC 60601-1-2 for Class B equipment.
39
This product has a very low emission and should not
interfere with other equipment.
However, if other devices nearby should react
inexplicably, run and stop this product and observe
the devices.
If nothing happens with the other devices, then
l
this product is not causing the error.
If other devices are behaving in an inexplicable
l
manner, then this product is causing the error.
Solve the problem by moving or increasing the
distance between them.
8.7 EMC - Manufacturer´s declaration
Basic
Test
Standard
Mains
PortConducted EN 55011
Emissions
Radiated
EN 55011
Emissions
EN 61000-3-
Mains Harmonics
2 +A1 + A2
Voltage
EN 61000-3-3 dc%/dmax/d(t)/Pst
Fluctuations
Electrostratic
EN 61000-4-2
Discharge
Radiated Field
EN 61000-4-3
Immunity
EFT/Bursts EN 61000-4-4 ±2kV L/N/E/LNE
Surge Immunity EN 61000-4-5
Conducted RF
EN 61000-4-6
Immunity
Magnetic Field
EN 61000-4-8 3A/m, 50Hz-80Hz
Immunity
Dips & EN 61000-4-
Interruptions 11
Compliance Level /
Frequency Range
Group 1 Class B
Group 1 Class B
Class A
±2/4/6kV Contact,
±2/4/8kV Air
3V/m, 80% 1kHz AM,
80MHz - 2.5 GHz
±0.5/1kV L-N,
±0.5/1/2kV L-E/N-E
3V, 80% 1kHz AM,
0.15MHz - 80MHz
-95%/-60%/-30%
