Rea® Azalea®
Adjust the brake effect with the adjustment nut A         o n the
wire.

  2.
When the desired brake effect is achieved, fixate the         b rake
wire with the fixation nut B.
WARNING!
Risk of injury
Poor brake effect
— Check the brake effect after mounting or
adjusting the brake.
30
B
B
1580313-K
