Rea® Azalea®

12.2 Material

Chassis, backrest tubes
Plastic parts like push handles, brake handles, foot plates
and parts of most accessories
Upholstery (seat and backrest)
Table
Seat plate
Other metal parts
Screws, washers and nuts

12.3 Environmental conditions

Temperature
Relative humidity
Atmospheric pressure
Be aware that when a wheelchair has been stored under low temperatures, it must be adjusted to operating conditions
before use.
12.4 Electrical system — Models equipped with electric tilt and backrest
Voltage supply
Maximum current input
Intermittent (periodic
motor operation)
Protection class
Degree of protection
For full details, also read the documentation from the manufacturer. Download manual(s) from www.linak.com
or contact your Invacare dealer.

12.5 Electromagnetic compliance (EMC)

General information
Products with electronic equipment needs to be installed and used according to the EMC information in this user manual.
WARNING!
Portable and mobile communications equipment can affect the operation of this product.
This product must not move unintentionally while being submitted to Electromagnetic interference
– If this should happen; the product must immediately be taken out of use and checked by a trained technician.
This product has been tested and complies with the EMC limits specified by IEC 60601-1-2 for Class B equipment.
50
Long term / Short term storage
U in 100–240 Voltage, AC, 50/60 Hz (AC = Alternating current), DC 24 V (DC = Direct current)
I in max. 5 Ampere (battery = max 1,3 Ampere)
10 % 2 min ON / 18 min OFF
CLASS II equipment
Applied Part complying with the specified requirements for protection against electrical shock
according to IEC60601-1.
The control unit, external power supply, motors and hand controls are protected according to
IPx6. See label and label on each electric device for correct IP class. The lowest IP-classification
decides the overall classification of the system.
IPx6- The system is protected against water projected from any direction (not high pressure).
Steel, powder coated
Thermoplastic (e.g. PA, PE, PP, ABS and TPE) according to
marking on the parts
Foam PUR and Polyether, fabric Dartex® and plush
ABS
Coated Birch plywood
Zink alloys, aluminium alloys and steel
Steel, corrosion free
and transportation
-10º C to +50º C
20% to 75%
800 hPa to 1060 hPa
Operation
-5º C to +40º C
