Roaming SIMs
The unit has two SIMs.
y SIM 1 – EE network sim with 4G
and 2G.
y SIM 2 – a UK roaming sim with 4G
and 2G network access.
The unit uses smart roaming to
determine which network to use.
Should network connectivity be lost
the unit will try different networks,
4G and 2G and will also swap SIMs if
required.
Should the unit lose connectivity
with the AddSecure platforms, or lose
registration with the current base
station, then the unit will roam onto the
next available 4G or 2G network.
www.addsecure.com
INTERCONNECTION MONITORING
Panel upload Download and
Enhanced format signalling
(SIA/CID)
Remote access to the alarm panel
can be achieved using the Addsecure
UDL facility. Additional panel set
up information is also available for
enhanced format signalling. Contact
your Addsecure representative for
further details.
Dial Capture
The Dial Capture pins present a 'phone
line' to the panel's onboard digital
communicator. Connect the alarm
panel's digital communicator line
connections to the terminals marked
DIAL CAP on the unit.
The terminals are not polarity
conscious.
Configure the alarm panel digital
communicator to dial 29 and use the
last 4 digits of the TAID as the account
number.
The Dial Capture board will auto
detect the panel protocol as events are
sent from the alarm panel. SIA, CID or FF.
Please check current panel
compatibility listing.
If there are any issues you can
easily spot them and put them right by
connecting a test phone, or listening
device to the Dial Capture inputs. The
Dial Capture pins with a test phone
connected and line seized (as if making
a phone call) will provide a continuous
tone (dialling tone). The Dial Capture
pins will also have a voltage on there
of 45V.
48
Serial panel connections
Select the required panel via the serial
panel type menu option via the buttons,
app or web portal.
Please contact your Addsecure
representative for the latest
information on panel compatibility
for Upload Download and enhanced
format signalling via serial connections.
Then wire in the panel using the GND,
TX/B and RX/A terminals.
