Configuration
Pin Learn
For speed of installation a single button
press Pin Learn is available. All pins
to be used should be wired in and all
the pins should be in the non alarm
state. No tampers should be active (if
wired in) and Pin 4 (open/close) should
represent the system being set/closed.
When ready, press and hold the
down arrow for 3s. 'Notice – Done!'
is displayed when finished. This has
completed the Pin Learn. There is also
an option to learn the pins within the
configuration menu.
Configuration menu
programming
The unit is supplied pre-configured
with factory default values. For
most installations no changes to the
configuration are required.
Press & Hold for Pin Learn
Notice –
Done!
www.addsecure.com
CONFIGURATION
The unit can either be configured
by using the on-board configuration
menu driven by the buttons, or through
the installer app or web portal. Some
configurations are only available
through the app or web portal. For
use of the app or web portal remotely,
written authorisation is required from a
Level 2 user.
A minority of sites may require
minimal configuration changes at
installation, and most of these will
be achievable through the button
configuration, e.g:
y Change the individual pin status.
y
Enable Dual End of Line for
interconnection monitoring.
y
Change the IP mode from Ethernet to
wi-fi.
y
Change from dynamic to static IP
addressing, and allocate a static IP
address/subnet/gateway address.
