Programming
Unit initialisation
The unit will immediately attempt to
connect to the Addsecure platform
over the configured paths. The unit will
typically complete path establishment
in the following times from power up.
IP 120s
4G/2G
120s
Figure 4 – Time to commission paths after
unit power up
Status display
The unit clearly displays its status on
the OLED. In its normal working state,
the unit will cycle its display.
www.addsecure.com
PROGRAMMING
Path: Ethernet
Registered
IP Path and if registered with the platform.
Mobile1 Strength
4G[ ] [-103]


Signal strength – network type (4G or 2G)
received wireless signal strength in dBm
and signal strength indicator bars. Two
bars or more is the recommended signal
level required.
The performance category can only be determined by the unit while in contact with the platform.
The unit will not show the performance category until at least one path is registered and the
profile can be retrieved from the platform.
Alarms GPI Alarm
3
Pin status – any outstanding alarm pins will
be shown. If no pins are in the alarm state,
then pin status will not be shown..
13
Mobile Path and if registered
with the platform.
Mobile1 Operator
EE
Shows the mobile network that the device
is connected to.
Alarms Battery
Low Battery
The unit may also show Low Battery if
the supply voltage is below the supply
threshold.
NGP Advanced and NGP Advanced Extra
Service Grade
Redcare DP3
Service Grade – shows the EN Performance
category. DP2 for NGP Advanced, DP3 for
NGP Advanced Extra.
