AddSecure NGP Advanced Installation Manual page 29

Then use to step to gateway address, and use the same
process as above to set the subnet address.
ETH Subnet Addr
1
255.255.255.15
ETH IP Addr*
3
0 00.000.000.000
Press until correct number
First digit
highlighted
Press to get to next digit
ETH GW Addr*
5
1 0 0.000.000.000
Press until correct number
Second digit
highlighted
Press to get to next digit
ETH GW Addr*
7
19 0 .000.000.000
Press until correct number
Third digit
highlighted
Press and hold
Notice -
9
Saved!
www.addsecure.com
MAIN MENU DISPLAY
ETH GW Addr
2
0.0.0.0
ETH GW Addr*
4
1 00.000.000.000
ETH GW Addr*
6
1 9 0.000.000.000
ETH GW Addr*
8
19 2 .000.000.000
Use enter to step along IP address digits 4-12
Use up and down to change individual digits
Press and hold Enter when finished
ETH GW Addr
192 .168.1.254
Note that IP addresses are made up of 12 digits in 4
batches of 3, separated by dots. When the addresses are
entered through the buttons they must be put in as 12 digit
numbers, with zeros used to the left of each batch where
necessary to pad out the addresses, e.g.:
y IP Address = 192.168.001.056
y Subnet mask = 255.255.255.015
y Gateway = 192.168.001.254
The full address will be shown on the display for each of
the above.
Edit mode for that part of the menu can be exited at
any time, without saving changes, by pressing
This will return you to the sub-menu that you were making
changes in.
The configuration menu can be exited at any time
without saving any changes by pressing
will take you back to the scrolling status display.
29
for 5s.
for 5s. This
NGP Advanced and NGP Advanced Extra
