Button configuration
Enter the button configuration mode by
holding down the centre configuration
button (Enter) for three seconds.
When in the main menu, each press
of will step to the next menu item
down.
Use to step back up and
eventually return to the top of the
menu. The full main menu options are
shown in Fig. 7.
www.addsecure.com
CONFIGURATION
The unit will then display
'Configuration'.
Configuration
Press the Enter button again and
the display will show the first menu
option.
Inputs
Pressing the Enter button on any
menu item will enter the sub-menu
and take you into edit mode. This will
allow the function to be changed. The
structure of the sub-menu depends on
the menu item.
Output Type 1*
Single Path Fault
You know you are in edit mode and
that changes can be made by a * next to the
menu title.
Some menu items have more options.
For example, Output 2 has four options
to set the comms fault output type. On
such menus, press the Enter button to
enter the sub-menu, then use the down
and up arrows to increment through the
options with each press. Holding the
Enter button for 5s will save changes.
Display will show 'Notice – Saved!'
Some more complex menu items use
the Enter button to also step through
additional items in the sub-menu. E.g.
Network IP addresses to be input.
19
Notice -
Saved!
Typically, many menu items simply have
two options, use the down and up arrow to
switch between the two. Press and hold the
Enter button to save changes. Display will
show 'Notice – Saved!'
Edit mode can be exited at any time,
without saving changes, by pressing
for 5s. This will return you to
the sub-menu that you were making
changes in.
The configuration menu can be
exited at any time without saving any
changes by pressing for 5s. This
will take you back to the scrolling status
display.
