Network
The programming options under the network sub-
menu are:
y
DSL/FTTP mode – Allows the unit to be changed
between dynamic (DHCP client) or Static mode.
Default setting is DHCP. The Ethernet port will
attempt to obtain an IP address from a DHCP server
on the LAN.
y IP address – shows current IP address but can also be
configured for a static IP address.
y Subnet mask address – shows current subnet address
but can also be configured for a customer's subnet
address.
y
Gateway address – shows current gateway address
but can also be configured for a customer's gateway
address.
y DNS Address 1 – can be configured to use specific
DNS servers.
y DNS Address 2 – can be configured to use specific
DNS servers.
y Tunnel Port – Port 443 is default but there is an
option to use 10443.
y Web passcode – used in conjunction with installer
and customer apps.
www.addsecure.com
MAIN MENU DISPLAY
When DHCP is set to disabled this then sets the unit in Static IP addressing mode.
Example – to change from DHCP to Static mode:
Configuration
1
Network
3
DSL/FTTP Mode*
5
DHCP
Notice –
7
Saved!
y
Access the configuration menu by
holding the Enter button for 3s. Press
the Enter button again, the display will
show 'Pin Learn'. Press the down arrow
until 'Network' is displayed. Press the
Enter button again. 'DSL/FTTP Mode' is
displayed. Press the Enter button. * will be
displayed. Use up arrow to switch to Static
IP addressing.
27
Inputs
Press until shows
DSL/FTTP
Mode
DHCP
DSL/FTTP Mode*
Static
Press and hold
y
Once selected hold the Enter button down till
'Notice – Saved!' is displayed.
Edit mode for that part of the menu can be
exited at any time, without saving changes, by
pressing for 5s. This will return you to the
sub-menu that you were making changes in.
The configuration menu can be exited at any
time without saving any changes by pressing
for 5s. This will take you back to the
scrolling status display.
