AddSecure NGP Advanced Installation Manual page 32

Example – changing the unit to connect to a Texecom Premier Elite panel via RS485:
Configuration
1
Press until shows
Serial Panel
3
Type
Panel Type*
5
None
Notice –
7
Saved!
www.addsecure.com
Inputs
Panel Type
None
Panel Type*
Texecom
Premier
Press until shows
Press and hold Press up arrow for
five seconds to exit
MAIN MENU DISPLAY
y
2
y
4
y
Edit mode for that part of the menu can be exited at any
time, without saving changes, by pressing
6
will return you to the sub-menu that you were making
changes in.
without saving any changes by pressing
will take you back to the scrolling status display.
32
Access the configuration menu by holding the Enter
button for 3s. Press the Enter button again, the display
will show 'Pin Learn'. Press the down arrow until serial
panel type is shown. Press the Enter button again to
enter serial panel Type. Default status = None will be
shown.
Use the down arrow to step through the available panel.
Once the desired Panel is reached press and hold the
Enter button down till 'Notice – Saved!' is displayed.
Then it will return to the same position in the menu for
you to select a different panel or use the down arrow to
step through all pins to get to the Back option.
The configuration menu can be exited at any time
NGP Advanced and NGP Advanced Extra
for 5s. This
for 5s. This
