AddSecure NGP Advanced Installation Manual page 26

Example – configure Output 1 (COMMS) for a single path fault:
Configuration
1
Output Type
3
Output Type 1*
5
BSIA 175
Notice –
7
Saved!
www.addsecure.com
Inputs
Output Type 1
BSIA 175
Output Type 1*
Single Path Fault
Press and hold
MAIN MENU DISPLAY
y
2
4
y
y
6
Edit mode for that part of the menu can be exited at any
time, without saving changes, by pressing
will return you to the sub-menu that you were making
changes in.
without saving any changes by pressing
will take you back to the scrolling status display.
26
Access the configuration menu by holding Enter button
for 3s. Press the Enter button again, the display will show
'Pin Learn'. Press the down arrow until 'Output Type'
is displayed. Press the Enter button again. The display
will show the default setting for Output type 1. Use the
down arrow to step through the Output types. Once the
desired output is reached press the Enter button. * will
be displayed. Use down or up arrow to change to the
required configuration for that output.
Once selected hold the Enter button down till 'Notice –
Saved!' is displayed.
Then it will return to the same position in the menu for
you to select another output or use the down arrow to
step through all outputs to get to the Back option.
