AddSecure NGP Advanced Installation Manual page 24

Inputs EOL
The alarm inputs (pins) can be set to the following modes:
y
None – (Alarm and Restore)
y
EOL (Single End of Line mode) – (Alarm, Restore and Cut)
y DEOL (Dual End of Line mode) – (Alarm, Restore, Cut and Short)
Example – configure Pin 1 for DEOL:
Configuration
1
Pin Learn
3
EOL 1
5
None
EOL 1*
7
DEOL
www.addsecure.com
Inputs
Inputs EOL
Press until shows
EOL 1*
None
Press twice
Notice –
Saved!
Press and hold
MAIN MENU DISPLAY
This allows the unit to monitor the wiring to the alarm
panel contacts.
y
y
2
y
y
4
Edit mode can be exited at any time, without saving
changes, by pressing
6
sub-menu that you were making changes in.
without saving any changes by pressing
will take you back to the scrolling status display.
8
24
Access the configuration menu by holding the Enter
button for 3s. Press the Enter button again, the display
will show 'Pin Learn'. Press the down arrow twice. The
display will show 'Inputs EOL'. Press the Enter button
again to enter Input EOL. 'EOL 1 = None' will be shown.
Use the down arrow to step through the pins. Once the
desired pin is reached press the Enter button. * will be
displayed. Use down or up arrow to change to None, EOL
or DEOL.
Once selected hold the Enter button down till 'Notice –
Saved!' is displayed.
Then it will return to the same position in the menu for
you to select another pin or use the down arrow to step
through all pins to get to the Back option.
for 5s. This will return you to the
The configuration menu can be exited at any time
NGP Advanced and NGP Advanced Extra
for 5s. This
